Diamond Interlock

Diamond Interlock is a heavy duty, interlocking rubber mat designed for quick and easy on-site installation in dry industrial environments. The mats are available as centre or end pieces for continuous lengths with bevelled edges to all sides for added safety. Along with being a very tough and durable mat, the moulded air pockets to the underside provide extra traction and ergonomic benefits.

Slip resistant 2

Great slip resistance to level 2

Anti-fatigue properties 3

Excellent anti-fatigue properties, resistant to level 3

Wear resistant 2

Great wear resistance to level 2, suitable for medium to high footfall

Connectable

Mats are connectable to create any shape or size

Disability friendly

Suitable for wheelchairs

Dry area

Suitable for use in dry areas

Wheeled area

Suitable for trolleys and wheeled trucks

Impact resistant

Able to resist sudden force or shock

Features

  • Heavy duty, interlocking rubber mat for simple on-site installation in dry industrial environments
  • Easily connectable to make long continuous lengths, with trip resistant bevels on all sides
  • Deckplate design and moulded air pockets underneath provide traction and ergonomic benefits
  • Material: Natural and recycled rubber
  • Overall height: 14mm

Technical Specification

Slip resistant
Great slip resistance to level 2
Anti-fatigue
Excellent anti-fatigue properties, resistant to level 3
Wear resistant
Great wear resistance to level 2, suitable for medium to high footfall
Connectable
Yes, the mats are modular and interlocking
Disability friendly
Yes, the mats have ramped edges making them suitable for wheelchair users
Dry area
Yes
Wheeled area
Yes
Environment
Suitable for indoor use
Impact resistant
Yes
Product testing
  • Tensile strength: 3-3.5 Mpa
  • Hardness: 55+ Shore A
  • DIN abrasion loss mm3: 200 - 250%
  • Elongation at break: 200-250%
Sustainability
  • Nature friendly, biodegradable and recyclable
  • REACH (Registration, Evaluation, Authorisation and Restrictions of Chemicals)
  • Contributes to a cleaner environment by reducing the need to use cleaning chemicals
Temperature resistance
-20°C to +130°C
Cleaning
Wash with cold water, use a vacuum cleaner, or a pressure pump to remove dirt. The use of hard detergents is not recommended

Applications

Suitable for workshops, production lines, assembly areas and picking and packing stations.

Variants and Sizes

Code
Description
Thickness
Weight (kgs)
Colour
DC2831Diamond Interlock Centre Tile 71 x 78cm14mm4.4Black
DE2831Diamond Interlock End Tile 71 x 78cm14mm4.4Black
