    GRP Open Mesh Grating

    Our GRP Open Mesh Grating is a specially designed and moulded non-slip composite floor solution, constructed from the highest quality fibreglass making it lightweight and also chemical, rust, and corrosion resistant whilst offering longevity and durability. With limited tooling and installation costs, we can offer a vast range of standard length and width sizes, plus our in-house cutting service means we can offer bespoke sizes for that perfect fit.

    Available in 25mm, 38mm and 50mm thickness and an array of colours.

    Optional clips, bolts and clamps are available to purchase if required.

    Slip resistant 3

    Excellent slip resistance to level 3

    Wear resistant 3

    Excellent wear resistance to level 3, suitable for heavy footfall

    Chemical resistant

    Resistant for chemicals and oils

    Cut to size

    Product can be cut to bespoke sizes

    Disability friendly

    Suitable for wheelchairs

    Dry area

    Suitable for use in dry areas

    Wet area

    Suitable for use in wet environments

    Oily and greasy area

    Suitable for use in oily and greasy areas

    Heavy area

    Suitable for use in heavy duty areas

    Wheeled area

    Suitable for trolleys and wheeled trucks

    Flame retardant

    For use in fire risk areas

    Impact resistant

    Able to resist sudden force or shock

    Non-conductive (Electrical)

    Suitable for use in electrical areas

    Non-conductive (HV Electrical)

    Suitable for use in high voltage electrical areas

    UV resistant

    Resistant to UV rays

    Please select the sample you'd like for this product
    Data Sheet
    Loading...

    Features

    • Moulded non-slip composite floor grating
    • Constructed from the highest quality fibreglass making it lightweight, chemical, rust, and corrosion resistant ensuring longevity and durability
    • Cost-effective alternative to traditional materials like mild steel, stainless steel, aluminium, or wood
    • Limited tooling and installation costs
    • Standard and bespoke sizes available using our in-house cutting service
    • Material: GRP - Glass reinforced polyester with a resin coated gritted surface
    • Available in 25mm, 38mm and 50mm thickness
    • Fixing clips, bolts and clamps are available to purchase separately if required
    • Please note, cutting tolerance +/- 5mm

    Technical Specification

    Slip resistant
    Excellent slip resistance to level 3
    Wear resistant
    Excellent wear resistance to level 3, suitable for heavy footfall
    Anti microbial
    Yes
    Chemical resistant
    Yes
    Cut to length
    Yes
    Cut to size
    Yes
    Disability friendly
    Yes, the low profile makes it suitable for wheelchair users
    Dry area
    Yes
    Wet area
    Yes
    Oily and greasy area
    Yes
    Heavy area
    Yes
    Wheeled area
    Yes
    Environment
    Suitable for indoor and outdoor use
    Flame retardant
    Yes
    Impact resistant
    Yes
    Non-conductive (Electrical)
    Yes
    Non-conductive (HV Electrical)
    Yes
    Product testing
    • Slip resistance
      • Tested to BS7976.2 - PTV ‘Extremely Low’ for wet and dry conditions, PTV ‘Low’ for oily and greasy conditions
      • Coefficient of Friction (CoF): Dry 72; Wet 68 and Oil 63
    • Fire classification
      • EN 13501-1: Class B-s1, d0
      • ASTM E84-2018 Class 1
    • Load Certificate
      • BS EN 124 – Class A15
    • UV Certificate
      • UV Weather ISO 4892-2 Xenan Arc 5000hrs
    Sustainability
    • REACH (Registration, Evaluation, Authorisation and Restrictions of Chemicals)
    • RoHS (Restriction of Hazardous Substances)
    Temperature resistance
    -50°C to +110°C
    UV resistant
    Yes
    Cleaning
    Using a stiff brush will normally be sufficient to remove everyday dirt and debris. For more stubborn dirt, wash with warm water and a mild detergent, or a pressure washer on a low-pressure setting can also be used

    Applications

    Perfect solution for platforms, walkways, flooring, ramps and covers for industrial or construction sites, chemical and shipping industries as well as offshore oil rigs.

    Variants and Sizes

    Code
    Description
    Thickness
    Weight (kgs)
    Colour
    GR3939-25GNGRP Grating 996 x 996 x 25mm Sq Grit Top - Green12.5
    GR3939-25GYGRP Grating 996 x 996 x 25mm Sq Grit Top - Grey12.5
    GR3939-25YLGRP Grating 996 x 996 x 25mm Sq Grit Top - Yellow12.5
    GR3960-25GNGRP Grating 1492 x 996 x 25mm Sq Grit Top - Green18
    GR3960-25GYGRP Grating 1492 x 996 x 25mm Sq Grit Top - Grey18
    GR3960-25YLGRP Grating 1492 x 996 x 25mm Sq Grit Top - Yellow18
    GR3979-25GNGRP Grating 1985 x 996 x 25mm Sq Grip Top - Green25
    GR3979-25GYGRP Grating 1985 x 996 x 25mm Sq Grip Top - Grey25
    GR3979-25YLGRP Grating 1985 x 996 x 25mm Sq Grip Top - Yellow25
    GR3910-25GNGRP Grating 3010 x 996 x 25mm Sq Grit Top - Green37
    GR3910-25GYGRP Grating 3010 x 996 x 25mm Sq Grit Top - Grey37
    GR3910-25YLGRP Grating 3010 x 996 x 25mm Sq Grit Top - Yellow37
    GR4812-25GNGRP Grating 3660 x 1220 x 25mm Sq Grip Top - Green55
    GR4812-25GYGRP Grating 3660 x 1220 x 25mm Sq Grip Top - Grey55
    GR4812-25YLGRP Grating 3660 x 1220 x 25mm Sq Grip Top - Yellow55
    GR3939-38GNGRP Grating 996 x 996 x 38mm Sq Grip Top - Green20
    GR3939-38GYGRP Grating 996 x 996 x 38mm Sq Grip Top - Grey20
    GR3939-38YLGRP Grating 996 x 996 x 38mm Sq Grip Top - Yellow20
    GR3960-38GNGRP Grating 1492 x 996 x 38mm Sq Grip Top - Green29.25
    GR3960-38GYGRP Grating 1492 x 996 x 38mm Sq Grip Top - Grey29.25
    GR3960-38YLGRP Grating 1492 x 996 x 38mm Sq Grip Top - Yellow29.25
    GR3979-38GNGRP Grating 1985 x 996 x 38mm Sq Grip Top - Green40
    GR3979-38GYGRP Grating 1985 x 996 x 38mm Sq Grip Top - Grey40
    GR3979-38YLGRP Grating 1985 x 996 x 38mm Sq Grip Top - Yellow40
    GR3910-38GNGRP Grating 3010 x 996 x 38mm Sq Grip Top - Green58.5
    GR3910-38GYGRP Grating 3010 x 996 x 38mm Sq Grip Top - Grey58.5
    GR3910-38YLGRP Grating 3010 x 996 x 38mm Sq Grip Top - Yellow58.5
    GR4812-38GNGRP Grating 3660 x 1220 x 38mm Sq Grip Top - Green87
    GR4812-38GYGRP Grating 3660 x 1220 x 38mm Sq Grip Top - Grey87
    GR4812-38YLGRP Grating 3660 x 1220 x 38mm Sq Grip Top - Yellow87
    GR4812-50GNGRP Grating 3665 x 1225 x 50mm Sq Grip Top - Green115
    GR4812-50GYGRP Grating 3665 x 1225 x 50mm Sq Grip Top - Grey115
    GR4812-50YLGRP Grating 3665 x 1225 x 50mm Sq Grip Top - Yellow115
